| Dimensions | RTS2RB-3 | RTS2RB-6 |
| Length | 2.007 in.(50.98 mm) | 2.007 in.(50.98 mm) |
| Width | 1.100 in.(27.94 mm) | 1.100 in.(27.94 mm) |
| Height – Overall (with rail mount) | 1.66 in.(42.17 mm) | 1.66 in.(42.17 mm) |
| Height – Overall (without rail mount) | 1.275 in.(32.38 mm) | 1.275 in.(32.38 mm) |
| Weight (without rail mount) | 1.16 oz.(33 g) | 1.16 oz.(33 g) |
| Weight (without battery and rail mount) | 1.09 oz.(31 g) | 1.09 oz.(31 g) |
| Optics |
| Sight Window Width | 1.014 in.(25.76 mm) | 1.014 in.(25.76 mm) |
| Sight Window Height | .8665 in.(22.01 mm) | .8665 in.(22.01 mm) |
| Magnification | 1x | 1x |
| Lens | 100 % Parallax Free, Anti-Reflective Coated, Glass |
| Adjustments |
| 1 moa Clicks for windage / elevation | Yes | Yes |
| Positive Locking System | Yes | Yes |
| Elevation Adjustment Range | 180 in. @ 100 yds (457cm @ 100 m) |
| Windage Adjustment Range | 120 in. @ 100 yds (305cm @ 100 m) |
| Construction |
| Body Type | Aluminum | Aluminum |
| Electronics |
| Intensity Switch, 10 position, Push Button | Yes | Yes |
| Auto Off (After 8 hours of inactivity) | Yes | Yes |
| Dot Size | 3 moa | 6 moa |
| Battery – 3V Lithium, CR2032 | Yes | Yes |
| Battery Life(normal use) | 300-1500 hours | 300-1500 hours |
| Misc. |
| Operating Temperature Range | -13°F to +131°F (-25°C to +55°C) |
| Storage Temperature Range(No Battery) | -40°F to +158°F (-40°C to +70°C) |
| Water Resistance Depth | 1 m | 1 m |
