| Article number | 11972 |
| Technology | ACET (Advanced Circuit Efficiency Technology) |
| Working principle | Reflex collimator sight – red dot sight |
| OPTICAL DATA | |
| Lightsource | LED (Light Emitting Diode) totally eye-safe |
| Lightsource wavelength | 650 nm red light |
| Red dot size in MOA (minute of angle)* | 2 |
| Parallax | Absence of parallax – No centering required |
| Eye relief | Unlimited |
| Night vision compatibility | Yes |
| Anti-reflex coating all surfaces & multi-layer coating objective lens | Yes |
| Magnification | No magnification (1X) |
| ELECTRONIC DATA | |
| Battery | One AA battery, accepts 1.5-5V – high battery compartment |
| Battery life in hours ** | 80 000 (over 8 years of continuous use) |
| Battery life in hours **at NVD settings *** | 500 000 |
| Dot intensity adjustment | Manual rotary switch – high switch location |
| Daylight (DL) settings | 9 DL of which one extra bright |
| NVD settings | 7 NVD |
| MECHANICAL DATA | |
| Material housing | Extruded high strength aluminum |
| Surface finish | Hard anodized, matte |
| Color housing | Black |
| Adjustment 1 click | 16mm at 100m, (1/2” at 80yds) |
| Mounting methods | Integrated QRP2 – (Quick release) |
| ENVIROMENTAL DATA | |
| Temperature range | -45° – +71° C, (50°- +160° F) |
| Water resistance – submersible to | 45m, (150ft) |
| Radioactive components used | None |
| DIMENSIONS | |
| Length | 120mm, (4.7”) |
| Width/height sight only | 53 x 60mm, (2.1” x 2.4”) |
| Width/height including mount | 72 x 72mm, (2.8” x 2.8”) |
| Weight sight only | 265g, (9.3oz) |
| Weight sight with integrated mount | 335g, (11.8oz) |
** at room temperature & at setting 12 out of 16 – (Figures valid for a good quality 1.5V) alkaline AA battery).
*** Night Vision Device.
