| Article number | 11421 |
| Technology | ACET (Advanced Circuit Efficiency Technology) |
| Working principle | Reflex collimator sight – red dot sight |
| OPTICAL DATA |
| Lightsource | LED (Light Emitting Diode) totally eye-safe |
| Lightsource wavelength | 650 nm red light |
| Red dot size in MOA (minute of angle)* | 2 |
| Parallax | Absence of parallax -No centering required |
| Eye relief | Unlimited |
| Night vision compatibility | No |
| Anti-reflex coating all surfaces & multi-layer coating objective lens | Yes |
| Magnification | No magnification (1X) |
| ELECTRONIC DATA |
| Battery | One 3V Lithium battery, type 2L76 or DL1/3N |
| Battery life in hours ** | 50 000 (over 5 years of continuous use) |
| Dot intensity adjustment | Manual rotary switch |
| Daylight (DL) settings | 1 Off & 9 DL |
| MECHANICAL DATA |
| Material housing | High strength aluminum |
| Surface finish | Anodized, semi-matte |
| Color housing | Black |
| Adjustment 1 click | 13mm at 100m, (1/2” at 100yds) |
| Mounting methods | 1 ring, ø 30mm |
| ENVIROMENTAL DATA |
| Temperature range | -30° – +60°C, (-20° – +140°F) |
| Water resistance – submersible to | Fully waterproof |
| Radioactive components used | None |
| DIMENSIONS |
| Length | 120m, (4.7”) |
| Maximum ring width | 30mm, (1.18”) |
| Objective diameter | 38mm, (1.5”) |
| Tube diameter | 30mm, (1.18”) |
| Weight sight only | 200g, (7.1oz) |
